Assessment of micropollutants removal efficiency by an integrated MBR-RO process for wastewater and reuse
Email:
vtnga@utc.edu.vn
Keywords:
membrane bioreactor MBR, reverse osmosis RO, integrated MBR-RO, domestic wastewater, micropollutants
Abstract
The membrane bioreactor (MBR) process can produce consistently hight quality of effluent from municipal wastewater, it is not always possible to use this water directly as irrigation and process water if especially the micropollutants in water is high. Therefore, additional treatment, such as reverse osmosis (RO), should be followed to produce excellent quality water by removing micropollutants. This study focuses on the application of a combined MBR-RO process for removal of various pollutants, especially micropollutants, in urban wastewater. Three pharmaceutical micropollutants, including carbamazepine, diclofenac and ketoprofen, were selected to examine the removal capacity of the MBR and the integrated MBR-RO process. The results show that ketoprofen was easily removed by the biological treatment in the MBR (> 80%); meanwhile, the removal rate of carbamazepine could be negative (-7%), indicating that the concentration in the MBR permeate was higher than the influent concentration. The removal efficiency of diclofenac was low, at about 16%, in the MBR. However, the integrated membrane systems, MBR-RO, achieve higher removal rates of above 92% for all three micropollutants. Notably, good denitrification efficiency of the RO membrane was observed, > 86%, demonstrating that the reverse osmosis membrane might be used as tertiary treatment after a membrane bioreactor to achieve higher water quality recoveryReferences
[1]. S.H. Zahraa, H.A. Gzar, Evaluation of the performance of MBR-RO technology for treatment of textile wastewater and reuse, IOP Conf. Series: Materials Science and Engineering, 584 (2019) 012049.
[2]. N.J. Falizi, M.C. Hacifazlioglu, I. Parlar, N. Kabay, T. Ö.Pek, M. Yûksel, Evaluation of MBR treated industrial wastewater quality before and after desalination by NF and RO processes for agricultural reuse, Journal of Water Process Engineering, 22 (2018) 103-108. https://doi.org/10.1016/j.jwpe.2018.01.015
[3]. G. Sert, S. Bunani, N. Kabay, Ö. Egement, M. Arda, T. Ö. Pek, M. Yüksel, Investigation of mini pilot scale MBR-NF and MBR-RO integrated systems performance- Preliminary field tests, Journal of Water Process Engineering, 12 (2016) 72-77. http://dx.doi.org/10.1016/j.jwpe.2016.06.008
[4]. M. Aziz, G. Kasongo, The removal of selected inorganics from municipal membrane bioreactor wastewater using UF/NF/RO membranes for water reuse application: A pilot-scale study, Membrane, 11 (2021) 117. https://dx.doi.org/10.3390/membranes11020117
[5]. A. Plevri, C. Noutsopoulos, D. Mamais, C. Makropoulos, A. Andreadakis, E. Lytras, S. Samios, Priority pollutants and other micropollutants removal in an MBR-RO wastewater treatment system, Desalination and Water Treatment, 127 (2018) 121-131.
[6]. L. Goswami, R. Vinoth Kumar, S. N. Borah, N. A. Manikandan, K. Pakshirajan, G. Pugazhenthi, Membrane bioreactor and integrated membrane bioreactor systems for micropollutants removal from wastewater: A review, Journal of Water Process Engineering, 26 (2018) 314-328.
[7]. M. Aziz, T. Ojumu, Exclusion of estrogenic and androgenic steroid hormones from municipal membrane bioreactor wastewater using UF/NF/RO membranes for water reuse application, Membrane, 10 (2020) 37.
[8]. Y. Wang, X. Wang, M. Li, J. Dong, C. Sun, G. Chen, Removal of pharmaceutical and personal care products (PPCPs) from municipal wastewater with integrated membrane systems, MBR-RO/NF, Int. J. Environ. Res. Public Health, 15 (2018) 269. https://doi.org/10.3390/ijerph15020269
[9]. M. Racar, D. Dolar, K. Karadakic, N. Cavarovic, N. Glumac, D. Asperger, K. Kosutic, Challenges of municipal wastewater reclamation for irrigation by MBR and NF/RO: Physico-chemical and microbiological parameters, and emerging contaminants, Science of the total environment, 722 (2020) 137959. https://doi.org/10.1016/j.scitotenv.2020.137959
[10]. P. Cartagena, M. EI Kaddouri, V. Cases, A. Trapote, D. Prats, Reduction of emerging micropollutants, organic matter, nutrients, and salinity from real wastewater by combined MBR-NF/RO treatment, Separation and Purification Technology, 110 (2013) 132-143. https://doi.org/10.1016/j.seppur.2013.03.024
[11]. J. Sipma, B. Osuna, N. Collado, H. Monclús, G. Ferrero, J. Comas, I. Rodriguez-Roda, Comparison of removal of pharmaceuticals in MBR and activated sludge systems, Desalination, 250 (2010), 653-659. https://doi.org/10.1016/j.desal.2009.06.073
[12]. C. Li, C. Cabassud, C. Guigui, Evaluation of membrane bioreactor on removal of pharmaceutical micropollutants: a review, Desalination and water treatment, 55(4) 2015.
[13]. R. Li, H. Kadrispahic, M.K. Jorgensen, S.B. Berg, D. Thornberg, A.T. Mielczarek, K. Bester, Removal of micropollutants in a ceramic membrane bioreactor for the post-treatment of municipal wasterwater, Chemical Engineering Journal, 427 (2022) 13145.
[14]. J. Park, N. Yamashita, C. Park, T. Shimono, D.M. Takeuchi, H. Tanaka, Removal characteristics of pharmaceuticals and personal care products: Comparison between membrane bioreactor and various biological treatment processes, Chemosphere, 179 (2017) 347-358. https://doi.org/10.1016/j.chemosphere.2017.03.135
[15]. J. Mamo, M.J. García-Galán, M. Stefani, S. Rodriguez-Mozaz, D. Barceló, H. Monclús, I. Rodriguez-Roda, J. Comas, Fate of pharmaceuticals and their transformation products in integrated membrane systems for wastewater reclamation, Chem. Eng. J, 331 (2018) 450-461.
[2]. N.J. Falizi, M.C. Hacifazlioglu, I. Parlar, N. Kabay, T. Ö.Pek, M. Yûksel, Evaluation of MBR treated industrial wastewater quality before and after desalination by NF and RO processes for agricultural reuse, Journal of Water Process Engineering, 22 (2018) 103-108. https://doi.org/10.1016/j.jwpe.2018.01.015
[3]. G. Sert, S. Bunani, N. Kabay, Ö. Egement, M. Arda, T. Ö. Pek, M. Yüksel, Investigation of mini pilot scale MBR-NF and MBR-RO integrated systems performance- Preliminary field tests, Journal of Water Process Engineering, 12 (2016) 72-77. http://dx.doi.org/10.1016/j.jwpe.2016.06.008
[4]. M. Aziz, G. Kasongo, The removal of selected inorganics from municipal membrane bioreactor wastewater using UF/NF/RO membranes for water reuse application: A pilot-scale study, Membrane, 11 (2021) 117. https://dx.doi.org/10.3390/membranes11020117
[5]. A. Plevri, C. Noutsopoulos, D. Mamais, C. Makropoulos, A. Andreadakis, E. Lytras, S. Samios, Priority pollutants and other micropollutants removal in an MBR-RO wastewater treatment system, Desalination and Water Treatment, 127 (2018) 121-131.
[6]. L. Goswami, R. Vinoth Kumar, S. N. Borah, N. A. Manikandan, K. Pakshirajan, G. Pugazhenthi, Membrane bioreactor and integrated membrane bioreactor systems for micropollutants removal from wastewater: A review, Journal of Water Process Engineering, 26 (2018) 314-328.
[7]. M. Aziz, T. Ojumu, Exclusion of estrogenic and androgenic steroid hormones from municipal membrane bioreactor wastewater using UF/NF/RO membranes for water reuse application, Membrane, 10 (2020) 37.
[8]. Y. Wang, X. Wang, M. Li, J. Dong, C. Sun, G. Chen, Removal of pharmaceutical and personal care products (PPCPs) from municipal wastewater with integrated membrane systems, MBR-RO/NF, Int. J. Environ. Res. Public Health, 15 (2018) 269. https://doi.org/10.3390/ijerph15020269
[9]. M. Racar, D. Dolar, K. Karadakic, N. Cavarovic, N. Glumac, D. Asperger, K. Kosutic, Challenges of municipal wastewater reclamation for irrigation by MBR and NF/RO: Physico-chemical and microbiological parameters, and emerging contaminants, Science of the total environment, 722 (2020) 137959. https://doi.org/10.1016/j.scitotenv.2020.137959
[10]. P. Cartagena, M. EI Kaddouri, V. Cases, A. Trapote, D. Prats, Reduction of emerging micropollutants, organic matter, nutrients, and salinity from real wastewater by combined MBR-NF/RO treatment, Separation and Purification Technology, 110 (2013) 132-143. https://doi.org/10.1016/j.seppur.2013.03.024
[11]. J. Sipma, B. Osuna, N. Collado, H. Monclús, G. Ferrero, J. Comas, I. Rodriguez-Roda, Comparison of removal of pharmaceuticals in MBR and activated sludge systems, Desalination, 250 (2010), 653-659. https://doi.org/10.1016/j.desal.2009.06.073
[12]. C. Li, C. Cabassud, C. Guigui, Evaluation of membrane bioreactor on removal of pharmaceutical micropollutants: a review, Desalination and water treatment, 55(4) 2015.
[13]. R. Li, H. Kadrispahic, M.K. Jorgensen, S.B. Berg, D. Thornberg, A.T. Mielczarek, K. Bester, Removal of micropollutants in a ceramic membrane bioreactor for the post-treatment of municipal wasterwater, Chemical Engineering Journal, 427 (2022) 13145.
[14]. J. Park, N. Yamashita, C. Park, T. Shimono, D.M. Takeuchi, H. Tanaka, Removal characteristics of pharmaceuticals and personal care products: Comparison between membrane bioreactor and various biological treatment processes, Chemosphere, 179 (2017) 347-358. https://doi.org/10.1016/j.chemosphere.2017.03.135
[15]. J. Mamo, M.J. García-Galán, M. Stefani, S. Rodriguez-Mozaz, D. Barceló, H. Monclús, I. Rodriguez-Roda, J. Comas, Fate of pharmaceuticals and their transformation products in integrated membrane systems for wastewater reclamation, Chem. Eng. J, 331 (2018) 450-461.
