Experiment and numerical study on shear behavior of reinforced concrete deep beams with opening
Email:
nguyenxuanhuy@utc.edu.vn
Keywords:
deep beam, web opening, Cast3M, opening location, size, shape
Abstract
Openings are often developed in deep beam to facilitate passage of necessary such as drinking water, sewage, air conditioning and electricity, internet or decrease the dead load. This paper investigated experimentally and numerically the shear behavior of reinforced concrete deep beam with web opening. Firstly, two deep beams without and with square opening were constructed and tested under three-point bending. Then, the 3D numerical model was created using the finite element analysis software Cast3M. The behavior of concrete was simulated using the Mazars 3D damage concrete model. The behavior of reinforced steel was assumed as a elastic perfectly plastic. The numerical results showed a good agreement with the experimental results in terms of load – displacement curve, failure mode. Then, a parametric study was carried out to investigate the effect of opening location, size, shape on the shear behavior of deep beam. The developed finite element model was found to be effective in accurately predicting the shear behavior of reinforced concrete deep beamReferences
